Baja Designs

Baja Designs Squadron SAE LED Auxiliary Light Pod Pair - Universal

Regular price $349.95 USD
Regular price Sale price $349.95 USD
Sale Sold out
Shipping calculated at checkout.
LIGHT PATTERN
COLOR

DESCRIPTION

Baja Designs SAE products are experiencing 8-10 weeks average lead times. We are shipping orders as quickly as possible.

Baja Designs next generation Squadron® SAE is the perfect road-legal auxiliary fog light on the market today. Engineered with all-new aspheric projector optics and with our advanced LED technology provides a performance increase in luminous flux of 56% over our previous generation SAE model. The all-new Squadron® SAE delivers 2,420 lumens per light with output reaching up to 15,800 candela at just 29 watts. Keeping you safe on the road or trails, the Squadron® SAE will illuminate Zone 1 with a controlled, sharp cutoff from the combination of the new LED technology and highly efficient aspheric projector optics. Designed to meet the current SAE J583 fog lamp requirements, the Squadron® SAE is fully compliant with on-road regulations. This innovative approach allows for a highly controlled light pattern with a sharp cutoff, making them an ideal choice for driving through dust, fog, and inclement weather. Backed by our limited lifetime warranty and 30-day satisfaction guarantee, giving you the ultimate in-purchase protection. USPTO Reg No. 5,766,659

Satisfaction Guarantee – 30-Day Money Back Guarantee

Limited Lifetime Warranty – Complete Purchase Protection

uService – Replaceable Lenses And Optics

ClearView – All The Light, Right Where You Need It

MoistureBlock – Waterproof, Rain Proof, Submersible

CopperDrive – Only LED Driven At 100 Percent

5000K Daylight – Less Driver Fatigue, Natural Color

DETAILED SPECS

SKU: 257801

Dimensions

Depth (in.) 2.770
Height (in.) 3.070
Length (in.) 3.070
Weight (lbs.) 0.750

Specifications

Amperage Rating (A) 2.1
Average Rated Life (hr.) 49930
Beam Pattern SAE Fog
Bezel Material Billet Machined Aluminum
Brightness (Lumens) 2420
Description SAE Fog; Clear; Pair
Housing Color Black
Housing Material Hard Anodized and Powder Coated Cast Aluminum
Lens Color Clear
Lighting Modes Hardcoated Polycarbonate
Light Quantity 2
Lens Material Beam
Lighting Quantity 4
Lighting Type Forward Projecting
Lighting Technology Cree LED
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Overvoltage Protection Built-In
Product Type Squadron SAE LED Light Pod Pair w/ Wiring Harness
Wattage (W) 29
Wiring Harness Included Yes

Standards & Compliance

DOT Approved No
Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Water Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)
Standards/Compliance (SAE) SAE Standard J583
Standards/Compliance (Impact Resistance) IK10 Compliant (Mechanical Impact Testing)
Street Legal Yes

SKU: 257811

Dimensions

Depth (in.) 2.770
Height (in.) 3.070
Length (in.) 3.070
Weight (lbs.) 0.750

Specifications

Amperage Rating (A) 2.1
Average Rated Life (hr.) 49930
Beam Pattern SAE Fog
Bezel Material Billet Machined Aluminum
Brightness (Lumens) 2420
Description SAE Fog; Amber; Pair
Housing Color Black
Housing Material Hard Anodized and Powder Coated Cast Aluminum
Lens Color Amber
Lighting Modes Hardcoated Polycarbonate
Light Quantity 2
Lens Material Beam
Lighting Quantity 4
Lighting Type Forward Projecting
Lighting Technology Cree LED
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Overvoltage Protection Built-In
Product Type Squadron SAE LED Light Pod Pair w/ Wiring Harness
Wattage (W) 29
Wiring Harness Included Yes

Standards & Compliance

DOT Approved No
Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Water Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)
Standards/Compliance (SAE) SAE Standard J583
Standards/Compliance (Impact Resistance) IK10 Compliant (Mechanical Impact Testing)
Street Legal Yes
